Bluetooth 5.1 small size ultra low energy module

Bluetooth 5.1 small size ultra low energy module
  • Bluetooth 5.1 small size ultra low energy module

BLM-MOD02 is a Bluetooth Low Energy 5.1 Module by Dialog DA14531 chipset. It’s a small BLE 5.1 module, the size is 15.0*10.0*2.6mm. The module support UART communication for data collection.


  • Product No.: BLM-MOD02

Details

Basic Parameter:

Bluetooth module model

BLM-MOD02

Bluetooth version

BLE 5.1

Chipset

Dialog DA14531

TX power

 -19.5 to +2.5dBm

Transmit range

100 meters

Dimension

15mm*10mm*2.6mm

Interface

UARTSPII2CPWMADC

Work temperature

-40ºC to +85ºC

Certification

 CE, FCC



Features:


 ● Bluetooth Low Energy Bluetooth 5.1

 ● Dialog DA14531

 ● FCC, CE Certificate

 ● Mini size: 15.0*10.0*2.6mm

 ● Up to 90m Work Range

 ● Support AT command to obtain module information and modify module parameters

Application:

 ● Bluetooth Beacon, iBeacon
 ● Bluetooth Gateway
 ● Smart home
 ● Bluetooth Printer
 ● Wireless Barcode Scanner
 ● Automotive Electronic

Documents:

BLM-MOD02 Datasheet:                                                           Download

BLM-MOD02 Programming User Guide                                  Download
